- Valve Gate: Air
- Air Blow: 2 Stage
- Max Clamp Stroke: 43″
- Minimum Mold Thickness: 14.2″
- Ejector Stroke: 7″
- Tie Bar Diameter: 5.5″
- Screw L/D Ratio: 25:1
2002 500 Ton Van Dorn, 89.6 oz.
Out of stock
Out of stock
| Brand | Van Dorn |
|---|---|
| Tonnage | 500 |
| Year | 2002 |
| Shot Size (oz.) | 89.6 |
| Clamp Style | Hydraulic |
| Tie Bar Distance (in.) | 34.9 x 34.9 |
| Platen (in.) | 49.6 x 49.6 |
| Maximum Daylight | 57.2 |
| Controller | Pathfinder 3000 |
| HKO | Yes |
| Corepull | 1 Stage, Yes |
| Model | 500SP4300 |
| Robot | Robot Interface |
| Voltage | 460 |
| Condition | Good |
